Jual Ductile Iron Gate Valve
RESILIENT WEDGE GATE VALVES with HYMAX Grip® Restraint
HYMAX Grip® Restraint tersedia pada Mueller A-2361 Resilient Wedge Gate Valves serta Super Centurion® 250 Fire Hydrants. Solusi restrain satu-baut ini menawarkan fleksibilitas luar biasa, karena dapat digunakan untuk menyambung berbagai jenis dan ukuran pipa, sehingga menghasilkan pemasangan yang lebih mudah dan efisien.
Jual Cast Steel Storm Valve Marine Jakarta Murah
Cast Steel Storm Valve Marine
Jual Cast Steel Storm Valve Marine, jual storm valve , harga storm valve marine, supplier storm valve marine , distributor storm valve marine, STORM VALVE CAST STEEL ANGLE FLANGED JIS F3060 10K, Storm Valve DN100 PN4/PN10, JIS F 3060 5K 125 Cast Steel Screw Down Vertical Angle Storm Valve
Jual Pneumatic Pinch Valve
Specification Product
- Size Range : 1″ (25mm) to 60″ (1500mm)
- Temperature : -50degF to 250degF
- Max. Working Pressure : Up to 300psi (20bar) (consult for higher pressures)
- Standard Face-to-Face : ASME B-16.10, DIN 3202, ISO 5732
- Flange Drilling : ANSI 150#, ANSI 300#, DIN, JIS, AS
- Actuation : Double or Single acting pneumatic, Fail Open or Close
- Tube Material : NR, PGR, EPDM, NBR, IIR, CR, FPM, CSMÂ (View Chart)
- In-Line Tube Change : Yes
- Wear Sensor : Yes, option
- Body Type : Enclosed or Sealed
- Ductile iron (CRN available) or aluminum
Jual Triple Offset Butterfly Valve
Jual Triple Offset Butterfly Valve
Jual Triple Offset Butterfly Valve, Jual Double Flange Offse t Disc Butterfly Valve, Jual Pneumatic Triple OffsetÂSpesifikasiÂ
| Merek | Sistem Kontrol Unik |
| Bahan | Besi tahan karat |
| Kekuatan | Hidrolik |
| Ukuran | 2 inci |
| Suhu Media | Suhu tinggi |
| Negara Asal | Buatan India |
| Jumlah Pesanan Minimum | 12 buah |
Jual FRL Air Control Unit
Jual FRL Air Control Unit, Harga Pneumatic Air Control Unit, jual air control unit, harga air control valve, Jual Valve Manifold Block Control Unit Air Suspension, Harga Head Unit Solenoid Air Control Valve Parker L6753910253, Jual Airtac Air Control Angle Seat Valve
Specification Product
| Operating Pressure | 1 to 8 Bar |
| Type | Filter Regulator |
| Port size | 1/2″ |
| Filtration u (micron) | 1, 5, 25, 40 (standard), 50, 100 |
| Applicable Temperature | 5 – 50 Degree Centigrade |
| Weight | 2.5 kg |
| Applicable Pressure Range | 0.2 – 2, 0.2 – 4, 0.5 – 7, 0.5 – 10 (Standard) |
| Max. Air flow | 3500 |
| Max. Pressure | 10 |
Jual Water Meter SHM 8 INCH DN 200 Jakarta
Description Product Water Meter SHM
- Flow Meter SHM 1 1/2 INCH 40mm Air Panas
- Size : 40mm ( 1 1/2 inch )
- Presure :Â 1,6 Mpa
- Overload Flow : 20 M³/Hour
- Permanent Flow : 10 M³/Hour
- Transitional Flow : 800 L/H
- Minimun Flow : 200 L/H
- Minimun reading : 0.00005 M³
- Maxiumun reading : 99,999
- Temperatur : 0,1°C-90°C For HOT
Wa
Jual ARITA Ball Valve Spring Return Deadman Handle 3/4″
ARITA Spring Return Deadman Handle Ball Valve 3/4″
ARITA Spring Return Deadman Handle Ball Valve 3/4″ Stainless Steel 304 Full Port 1500 PSI Female NPT, jual deadman valveProduct Details
| Manufacturer | Arita Valve |
| Part Number | ARTBVSS4NTA5020 |
| Item Weight | 2.1 pounds (0.95 kg) |
| Package Dimensions | 12.48 x 3.43 x 3.31 inches (31.7 x 8.7 x 8.4 cm) |
| Size | 3/4″ Female&Female (86.4 cm) |
| Material | Stainless Steel |
| Certification | Asme, ASTM |
| Batteries Included? | No |
| Batteries Required? | No |
| ASIN | B08R594M5W |
| Material | Stainless Steel |
| Brand | ARITA |
| Exterior Finish | Stainless Steel |
| Inlet Connection Type | National Pipe Tapered |
| Outlet Connection Type | FNPT |
| Certification | Asme, ASTM |
Jual Flange RTJ Terdekat Berkualitas
Jual Flange RTJ
Jual Flange RTJ, Jual Flange NPT, Jual Flange JIS, Jual Flange Lap Joint Slip On, Jual Flange Threaded, Jual Blind Flange, Harga Lap Joint flange , distributor flange PN, distributor Socket Weld flange, jual Flange Welding NeckDESKRIPSI
Size : 3″, 1/2″ ,3/4″, 1″ ,1-1/4″, 1-1/2″, 2″ ,2-1/2″, 4″, 3/4″ ,2″ ,5″ ,6″ ,8″, 10″ ,12″ ,14″, 16″ ,18″ ,20″, 24″, 10K, 20K, RF, FF, RTJ, STD Ansi : 150# 300# 600# 900# 1500# 2500# 3000# 5000# Brand : GBA, BEBITZ, PUYANG Material : Stainless Steel 304 / 316, Carbon Steel
Jual Dismantling Joint Ductile Iron Carbon Steel Cast Iron
Product Description
| Model No. | Dismantling Joint | Material: Ductile (GGG50/GGG45/GGG40/ASTM A536), Carbon Steel (ASTM A105) | |||
| Standard | EN545/EN598/ISO 2531 | Technics:Casting | |||
| Pressure | PN10/ PN16/PN25/PN40 | Specification: DN80*80—DN2000*2000 | |||
| Orginal | Packing:Fumigation Wooden Case/Non-Fumigation Wooden Case/Wooden Pallet | ||||
| Nominal Diameter | DN80*80—-DN2000*2000 | ||||
| Flanged Drilled | EN1092-2/DIN2501 | ||||
| Branch | Equal with Main Pipe/ Unequal with main pipe | ||||
| Pressure | PN10/PN16/PN25/PN40 | ||||
| Standard | EN545 (for portable water) EN598   (for swage water) | ||||
| Internal Coating | Cement mortar Lining(ISO4179) / Bitumen Painting(≥70μm)/ Fusion Bonded Epoxy Painting(or powder) | ||||
| External Coating | Sprayed Metallic Zinc Coating(ISO8179)&Bitumen Painting(≥70μm)/ Fusion Bonded Epoxy Painting(or powder) | ||||
| Application:Portable Water System/Sewage Water Syetem | |||||
PRODUK UNGGULAN
Jual Elbow 45 Derajat Long Radius (LR) Buttweld – ASME B16.9
jual elbow 45 45 degree long radius, & 90 Degree Long Radius stainless steel , jual elbow 45 & 90 Degree Long Radius astm , jual elbow 45 & 90 Degree Long Radius asme , jual elbow 45 & 90 Degree Long Radius benkan , jual elbow 45 & 90 Degree Long Radius sumitomo , jual elbow 45 & 90 Degree Long Radius tembaga , jual elbow 45 & 90 Degree Long Radius stainless steel , jual elbow 45 & 90 Degree Long Radius astm , jual elbow 45 & 90 Degree Long Radius asme , jual elbow 45 & 90 Degree Long Radius benkan , jual elbow 45 & 90 Degree Long Radius sumitomo , jual elbow 45 & 90 Degree Long Radius tembaga ansi
Pipa Seamless SS 304L Sch 10S
Pipa Seamless SS 304L Sch 10S, jual Pipa Seamless SS 304L 20S, jual Pipa Seamless SS 304L 40S, jual Pipa Seamless SS 304L 80S
Specifikasi & Ukuran
Pipa Seamless Stainless Steel 304 Sch 10S
Berikut adalah specifikasi teknis dan ukuran Pipa SS 304 Seamless Sch 10S :- Grade: SS 304L
- ASTMÂ : 312
- ASME : B36.19
- Ukuran: 1/4 – 12 Inch
- Panjang: 6 meter
- OD : 13,72 – 323,86 mm
- Tebal: 1,65 – 4,57 mm
Jual Elbow Long Bend 45 Degree
- Type : Seamless dan Welded
- Class : Long radius, short radius, 30 degree, 45 degree, 60 degree, 90 degree, 90 degree, 180 degree
- Size : Seamless Size from DN15 – DN700, Welded size DN200 – DN2000
- Thickness : SCH10, SCH20, SCH30, SCH40, SCH60, SCH80, SCH100, SCH120, SCH160, XS, XXS
- Material :
-
- A234 – WPB, WP5, WP9, WP11, WP22
- A420 – WPL3, WPL6
- A403 – WP304/L, WP316/L
- A860 – WPHY 42 – 46 / 52 -60/ 65 -70
- MONEL, INCONEL, Cu – Ni, Duplex SS
-
- STANDARD : ASME B16.9
- FACE : Coating
-
- Specials coating cement linning
- FBEÂ Coating
- Galvanized ( hot dip ellectro plating )
-
- Application : water disposal, electric power, chemical enginering, ship building, Nuclear Energy, Garbage disposal, Natural Gas, Petroleum Oil.Â
Pipa Medium Galvanis A53 GR B – Jual Pipa Galvanis A53 GR A
Specification of PIPA GALVANIS ASTM A53 GRADE A SCH 40 SPINDO / BAKRIE / ISTW
Pipa Medium Galvanis A53 GR B
Welded Pipe (ERW Steel Pipe)
Specifications:
– ASTM API5L GR.B / A53-B / X42 & A53 GR.A / A120
– SIZE 1/2 “- 26”
– Thickness: Sch 20, Sch 40
– Brand: Bakrie, Spindo, ISTW, GG, KHI Pipe, PPI, BK, Tysco Hyndai (South Korea), EEW (Malaysia)
Jual Gate Valve Kitz | Toyo | Tozen | Onda | Yone | Gala
Jual Gate Valve Kitz , Toyo , Tozen , Onda , Yone , Gala
Jual Gate Valve Kitz, supplier Gate Valve Velan, Distributor Gate Valve Tozen, Gate Valve Yone, harga Gate Valve EVO, Gate Valve Crane, Gate Valve Shoritsu, Gate Valve Asco, Gate Valve Tomoe, Gate Valve GLT, Gate Valve Bamboo, Gate Valve Riser, Gate Valve Weflo
Jual Haskel Hydrostatic Test Pump Systems
Jual Haskel Hydrostatic Test Pump Systems
Jual Haskel Hydrostatic Test Pump Systems, Jual Haskel Pump 10000 psi, Jual Asada Testing Pump, Jual Terada Water Pressure Test Pump, Jual Relief Valve Haskel 15700 – 25 Range 2500 – 25000 psi, Jual Relief Valve Haskel 1000 psi – 10000 psi, Jual Check Valve Haskel Gas Pressure 10000 psi ,
Jual Wrapping Tape Polyken 4 Inch X 100 fit
Jual Wrapping Tape Polyken
Harga Polyken Wrapping Tape, Harga Wrapping Polyken Tape Hitam, Harga Polyken Wrapping Tape putih, Harga Wraping Polyken Tape 4 Inch X 100fit, Harga Wraping Polyken 955, Harga Wraping Tape Polyken 980, Harga Polyken Wrapping Tape 2 Inc Putih
Basket Type Strainer
Jual Basket Type Strainer, Jual Strainer Basket, Basket Strainer, Jual Duplex Basket Strainer, Jual Basket Duplex Strainer, Jual Single Basket Strainer, Jual simplex Basket Strainer, Jual Stainless steel Basket Strainer, Harga Basket Strainer
Jual Pipa Seamless Stainless Steel 304L Sch 20S
Jual Pipa Seamless Stainless Steel 304L Sch 20S
Jual Pipa Seamless Stainless Steel 304L Sch 20S, Pipa Seamless Stainless Steel 304 Sch 10S, Pipa Seamless Stainless Steel 304 Sch 40S, Pipa Seamless Stainless Steel 304 Sch 80S- Grade: SS 304L
- ASTM : 312
- ASME : B36.19
- Ukuran: 1/4 – 18 Inch
- Panjang: 6 meter
- OD : 13,72 – 457,2 mm
- Tebal: 2,0 – 8,0 mm
- ID : 9,72 – 441,2 mm
pipa seamless stainless steel 304l sch20.xlsx
| Description product | Ukuran | OD | TEBAL | ID | BERAT/MTR | BERAT/BTG |
|---|---|---|---|---|---|---|
| Pipa Seamless Stainless Steel 304L Sch 20S DN 8 | 1/4 inch | 13,72 | 2 | 9,72 | 0,58 | 3,5 |
| Pipa Seamless Stainless Steel 304L Sch 20S DN 10 | 3/8 inch | 17,15 | 2 | 13,15 | 0,75 | 4,53 |
| Pipa Seamless Stainless Steel 304L Sch 20S DN 15 | 1/2 inch | 21,34 | 2,5 | 16,34 | 1,17 | 7,04 |
| Pipa Seamless Stainless Steel 304L Sch 20S DN 20 | 3/4 inch | 26,67 | 2,5 | 21,67 | 1,51 | 9,03 |
| Pipa Seamless Stainless Steel 304L Sch 20S DN 25 | 1 inch | 33,4 | 3 | 27,4 | 2,27 | 13,63 |
| Pipa Seamless Stainless Steel 304L Sch 20S DN 32 | 1 1/4 inch | 42,16 | 3 | 36,16 | 2,93 | 17,56 |
| Pipa Seamless Stainless Steel 304L Sch 20S DN 40 | 1 1/2 inch | 48,26 | 3 | 42,26 | 3,38 | 20,3 |
| Pipa Seamless Stainless Steel 304L Sch 20S DN 50 | 2 inch | 60,33 | 3,5 | 53,33 | 4,95 | 29,73 |
| Pipa Seamless Stainless Steel 304L Sch 20S DN 65 | 2 1/2 inch | 73,03 | 3,5 | 66,03 | 6,06 | 36,37 |
| Pipa Seamless Stainless Steel 304L Sch 20S DN 65 | 2 1/2 inch | 76,3 | 3,5 | 69,3 | 6,35 | 38,08 |
| Pipa Seamless Stainless Steel 304L Sch 20S DN 80 | 3 inch | 88,9 | 4 | 80,9 | 8,46 | 50,76 |
| Pipa Seamless Stainless Steel 304L Sch 20S DN 100 | 4 inch | 114,3 | 4 | 106,3 | 10,99 | 65,95 |
| Pipa Seamless Stainless Steel 304L Sch 20S DN 125 | 5 inch | 141,28 | 5 | 131,28 | 16,97 | 101,87 |
| Pipa Seamless Stainless Steel 304L Sch 20S DN 150 | 6 inch | 168,28 | 5 | 158,28 | 20,34 | 122,05 |
| Pipa Seamless Stainless Steel 304L Sch 20S DN 200 | 8 inch | 219,08 | 6,5 | 206,08 | 34,42 | 206,54 |
| Pipa Seamless Stainless Steel 304L Sch 20S DN 250 | 10 inch | 273,05 | 6,5 | 260,05 | 43,16 | 258,98 |
| Pipa Seamless Stainless Steel 304L Sch 20S DN 300 | 12 inch | 323,86 | 6,5 | 310,86 | 51,39 | 308,25 |
| Pipa Seamless Stainless Steel 304L Sch 20S DN 350 | 14 inch | 355,6 | 8 | 339,6 | 69,27 | 415,61 |
| Pipa Seamless Stainless Steel 304L Sch 20S DN 400 | 16 inch | 406,4 | 8 | 390,4 | 79,39 | 476,35 |
| Pipa Seamless Stainless Steel 304L Sch 20S DN 450 | 18 inch | 457,2 | 8 | 441,2 | 89,52 | 537,09 |
| Pipa Seamless Stainless Steel 304L Sch 20S DN 500 | 20 inch | 508 | 9,5 | 489 | 117,97 | 707,8 |
